ARB Airlocker 26 Spl 10 Bolt Rg Suzuki S/N - RD208

The world's premier traction aid, an ARB Air Locker(TM) keep you moving in all conditions. With the flick of the switch an Air Locker gives instant lock at any moment and its super strong design allows activation at any speed allowing you to tackle the toughest terrain. The advantage of the Air Locker lies in the pneumatically operated locking system inside the differential. When activated, the Air Locker prevents the internal differential gears from rotating and therefore prevents the axle shafts from turning independently of each other. With both wheels tied directly to the rotation of the ring gear, the vehicle maintains maximum possible traction at all times. When unlocked, it operates like a conventional open differential. An Air Locker equipped vehicle can be driven in a slower, safer and more controlled manner, greatly reducing the likelihood of vehicle damage and environmental impact.
Product Specifications Sheet
Warranty
Installation Instructions

• Easy, convenient operation allows the user to concentrate on the terrain without leaving the comfort and safety of the driver's seat
• Steel reinforced, elastomer bonded annular seal designed to handle the most extreme climatic temperatures on Earth
• Two-piece design is ultra-durable and extremely strong ? minimal moving parts ensure maximum reliability
• Kit includes: Air Locker differential, activation switch, solenoid valve, air line and bulkhead fitting
• Provides 100 percent traction on demand without affecting on-road drivability or driveline wear
• Patented ?timed' locking mechanism offers high strength and ultra-fast unlocking
• Employs Minimal Moving Parts Ensuring Maximum Reliability
• Air compressor required for operation (sold separately)

This Part Fits:

Year	Make	Model	Submodel
1989-1997	Geo	Tracker	Base
1989-1997	Geo	Tracker	LSi
1999	Suzuki	Grand Vitara	JLX
1999	Suzuki	Grand Vitara	JLX Plus
1999	Suzuki	Grand Vitara	JS
1999	Suzuki	Grand Vitara	JS Plus
1989	Suzuki	Samurai	Base
1986-1988,1991-1993	Suzuki	Samurai	JA
1990-1995	Suzuki	Samurai	JL
1991	Suzuki	Samurai	JS
1986-1988	Suzuki	Samurai	JX
1986-1987	Suzuki	Samurai	JX SE
1989	Suzuki	Sidekick	JA
1991	Suzuki	Sidekick	JL
1989-1995	Suzuki	Sidekick	JLX
1996-1998	Suzuki	Sidekick	JLX Sport
1990-1998	Suzuki	Sidekick	JS
1997-1998	Suzuki	Sidekick	JS Sport
1989-1998	Suzuki	Sidekick	JX
1996-1998	Suzuki	Sidekick	JX Sport
1999	Suzuki	Vitara	JS
1999	Suzuki	Vitara	JS Plus
1999	Suzuki	Vitara	JX
1999	Suzuki	Vitara	JX Plus
